Molex Connector Corporation 15-97-6081
- Mfg. Part Number
- 15-97-6081
- Manufacturer
- Molex Connector Corporation
- Product Category
- Rectangular Connectors - Housings
- Brief Description
- CONN PLUG 8POS DUAL MINI-FIT
- Datasheet Download
- 15-97-6081.pdf
Availability of 15-97-6081
Available Quantity
5708 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.38360
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 15-97-6081, we specialize in Molex Connector Corporation all series electronic components. 15-97-6081 can be shipped within 24 hours after order. If you have any demands for 15-97-6081, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 15-97-6081 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
15-97-6081
| Internal Part Number | EIS-15-97-6081 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Molex Mini-Fit® TPA | |
| RoHS Information | 15-97-6081 Cert of Compliance | |
| Featured Product | Mini-Fit® TPA Plugs and Receptacles | |
| 3D Model | 15-97-6081.stp | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Housings | |
| Series | Mini-Fit® TPA™ 30068 | |
| Packaging | Bulk | |
| Connector Type | Plug | |
| Contact Type | Male Pin | |
| Number of Positions | 8 | |
| Pitch | 0.165" (4.20mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.217" (5.51mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Contact Termination | Crimp | |
| Fastening Type | Locking Ramp | |
| Color | Black | |
| Features | - | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 15-97-6081 | |
| Related Links | 15-97, 15-97-6081 Datasheet, Molex Connector Corporation Distributor | |
