Curtis Industries 1511-ST
- Mfg. Part Number
- 1511-ST
- Manufacturer
- Curtis Industries
- Product Category
- Terminal Blocks - Barrier Blocks
- Brief Description
- Connector Barrier Block Strip 11 Circuit 0.375" (9.53mm)
- Datasheet Download
- 1511-ST.pdf
Availability of 1511-ST
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.49367
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1511-ST, we specialize in Curtis Industries all series electronic components. 1511-ST can be shipped within 24 hours after order. If you have any demands for 1511-ST, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1511-ST Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1511-ST
| Internal Part Number | EIS-1511-ST | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Barrier Blocks | |
| Series | 1500 | |
| Packaging | Bulk | |
| Terminal Block Type | Barrier Block | |
| Number of Circuits | 11 | |
| Number of Wire Entries | 22 | |
| Pitch | 0.375" (9.53mm) | |
| Number of Rows | 2 | |
| Current Rating | 20A | |
| Voltage Rating | - | |
| Wire Gauge | 12 AWG | |
| Top Termination | Screws with Solder Lugs, Dual | |
| Bottom Termination | Closed | |
| Barrier Type | 2 Wall (Dual) | |
| Features | Flange | |
| Color | - | |
| Terminal Screw Material | - | |
| Terminal Screw Finish | Tin | |
| Mounting Type | Chassis, Panel | |
| Operating Temperature | 110°C | |
| Material - Insulation | Polyphenylene Oxide (PPO) | |
| Material Flammability Rating | UL94 V-0 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1511-ST | |
| Related Links | 151, 1511-ST Datasheet, Curtis Industries Distributor | |
1511-ST Details Description
