API Delevan 1638R-06F
- Mfg. Part Number
- 1638R-06F
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 360UH 134MA 12.5 OHM
- Datasheet Download
- 1638R-06F.pdf
Availability of 1638R-06F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.41750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1638R-06F, we specialize in API Delevan all series electronic components. 1638R-06F can be shipped within 24 hours after order. If you have any demands for 1638R-06F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1638R-06F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1638R-06F
| Internal Part Number | EIS-1638R-06F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | 1638R | |
| Packaging | Tape & Reel (TR) | |
| Type | Molded | |
| Material - Core | Iron | |
| Inductance | 360µH | |
| Tolerance | ±1% | |
| Current Rating | 134mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 12.5 Ohm Max | |
| Q @ Freq | 65 @ 790kHz | |
| Frequency - Self Resonant | 4.8MHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 790kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Axial | |
| Size / Dimension | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | |
| Height - Seated (Max) | - | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1638R-06F | |
| Related Links | 1638, 1638R-06F Datasheet, API Delevan Distributor | |
1638R-06F Details Description
