TE Connectivity AMP Connectors 1776281-5
- Mfg. Part Number
- 1776281-5
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- TERM BLOCK PLUG 5POS STR 3.5MM
- Datasheet Download
- 1776281-5.pdf
Availability of 1776281-5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1776281-5, we specialize in TE Connectivity AMP Connectors all series electronic components. 1776281-5 can be shipped within 24 hours after order. If you have any demands for 1776281-5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1776281-5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1776281-5
| Internal Part Number | EIS-1776281-5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 17 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | Buchanan | |
| Packaging | Bulk | |
| Type | Plug, Female Sockets | |
| Number of Positions | 5 | |
| Positions Per Level | 5 | |
| Number of Levels | 1 | |
| Pitch | 0.138" (3.50mm) | |
| Header Orientation | - | |
| Plug Wire Entry | 180° | |
| Termination Style | IDC | |
| Mounting Type | Free Hanging (In-Line) | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 5A | |
| Voltage - UL | 250V | |
| Wire Gauge or Range - AWG | 22-24 AWG | |
| Wire Gauge or Range - mm² | 0.2-0.4mm² | |
| Color | Blue | |
| Operating Temperature | -40°C ~ 80°C | |
| Contact Mating Finish | Tin | |
| Features | Mating Flange | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1776281-5 | |
| Related Links | 1776, 1776281-5 Datasheet, TE Connectivity AMP Connectors Distributor | |
1776281-5 Details Description
