NorComp 180-062-102L001
- Mfg. Part Number
- 180-062-102L001
- Manufacturer
- NorComp
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Plug, Male Pins 62 Position Free Hanging (In-Line) Solder Cup
- Datasheet Download
- 180-062-102L001.pdf
Availability of 180-062-102L001
Available Quantity
5320 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.14800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 180-062-102L001, we specialize in NorComp all series electronic components. 180-062-102L001 can be shipped within 24 hours after order. If you have any demands for 180-062-102L001, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 180-062-102L001 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
180-062-102L001
| Internal Part Number | EIS-180-062-102L001 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | 180-062-102L001 Material Declaration | |
| Product Training Modules | D-Sub Connectors | |
| 3D Model | 180-062-10(2,3)Lxx1.pdf180-062-10(2,3)Lxx1.stp180-062-10(2,3)Lxx1.igs | |
| Standard Package | 40 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | 180 | |
| Packaging | Tray | |
| Connector Style | D-Sub, High Density | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 62 | |
| Number of Rows | 3 | |
| Shell Size, Connector Layout | 4 (DC, C) High Density | |
| Contact Type | Signal | |
| Mounting Type | Free Hanging (In-Line) | |
| Flange Feature | Housing/Shell (Unthreaded) | |
| Termination | Solder Cup | |
| Features | Grounding Indents, Shielded | |
| Shell Material, Finish | Steel, Tin Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | Flash | |
| Ingress Protection | - | |
| Operating Temperature | -50°C ~ 100°C | |
| Voltage Rating | - | |
| Current Rating | 5A | |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | |
| Color | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 180-062-102L001 | |
| Related Links | 180-062, 180-062-102L001 Datasheet, NorComp Distributor | |
180-062-102L001 Details Description
