Vishay Semiconductor/Diodes Division 1N6292HE3/73
- Mfg. Part Number
- 1N6292HE3/73
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 60.7VWM 109VC 1.5KE
- Datasheet Download
- 1N6292HE3/73.pdf
Availability of 1N6292HE3/73
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1N6292HE3/73, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. 1N6292HE3/73 can be shipped within 24 hours after order. If you have any demands for 1N6292HE3/73, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1N6292HE3/73 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1N6292HE3/73
| Internal Part Number | EIS-1N6292HE3/73 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | Automotive, AEC-Q101, TransZorb® | |
| Packaging | Tape & Box (TB) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 60.7V | |
| Voltage - Breakdown (Min) | 67.5V | |
| Voltage - Clamping (Max) @ Ipp | 109V | |
| Current - Peak Pulse (10/1000µs) | 13.9A | |
| Power - Peak Pulse | 1500W (1.5kW) | |
| Power Line Protection | No | |
| Applications | Automotive | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 175°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | DO-201AA, DO-27, Axial | |
| Supplier Device Package | 1.5KE | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1N6292HE3/73 | |
| Related Links | 1N6292, 1N6292HE3/73 Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
1N6292HE3/73 Details Description
