Aries Electronics, Inc. 20-8800-310C
- Mfg. Part Number
- 20-8800-310C
- Manufacturer
- Aries Electronics, Inc.
- Product Category
- Sockets for ICs, Transistors
- Brief Description
- CONN IC DIP SOCKET 20POS GOLD
- Datasheet Download
- 20-8800-310C.pdf
Availability of 20-8800-310C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.99000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 20-8800-310C, we specialize in Aries Electronics, Inc. all series electronic components. 20-8800-310C can be shipped within 24 hours after order. If you have any demands for 20-8800-310C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 20-8800-310C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
20-8800-310C
| Internal Part Number | EIS-20-8800-310C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Sockets for ICs, Transistors | |
| Series | 8 | |
| Packaging | Bulk | |
| Type | DIP, 0.3" (7.62mm) Row Spacing | |
| Number of Positions or Pins (Grid) | 20 (2 x 10) | |
| Pitch - Mating | 0.100" (2.54mm) | |
| Contact Finish - Mating | Gold | |
| Contact Finish Thickness - Mating | 30µin (0.76µm) | |
| Contact Material - Mating | Beryllium Copper | |
| Mounting Type | Through Hole | |
| Features | Closed Frame, Elevated | |
| Termination | Solder | |
| Pitch - Post | 0.100" (2.54mm) | |
| Contact Finish - Post | Gold | |
| Contact Finish Thickness - Post | 10µin (0.25µm) | |
| Contact Material - Post | Brass | |
| Housing Material | Polyamide (PA46), Nylon 4/6, Glass Filled | |
| Operating Temperature | -55°C ~ 105°C | |
| Termination Post Length | 0.140" (3.56mm) | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 3A | |
| Contact Resistance | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 20-8800-310C | |
| Related Links | 20-880, 20-8800-310C Datasheet, Aries Electronics, Inc. Distributor | |
20-8800-310C Details Description
