TE Connectivity AMP Connectors 2013012-3
- Mfg. Part Number
- 2013012-3
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN RECPT 50POS 0.6MM GOLD SMD
- Datasheet Download
- 2013012-3.pdf
Availability of 2013012-3
Available Quantity
5956 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.11200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2013012-3, we specialize in TE Connectivity AMP Connectors all series electronic components. 2013012-3 can be shipped within 24 hours after order. If you have any demands for 2013012-3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2013012-3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2013012-3
| Internal Part Number | EIS-2013012-3 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS compliant by exemption | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | Free Height (FH) | |
| Packaging | Tray | |
| Connector Type | Receptacle, Center Strip Contacts | |
| Number of Positions | 50 | |
| Pitch | 0.023" (0.60mm) | |
| Number of Rows | 2 | |
| Mounting Type | Surface Mount | |
| Features | Board Guide, Solder Retention | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Mated Stacking Heights | 4mm | |
| Height Above Board | 0.128" (3.25mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2013012-3 | |
| Related Links | 2013, 2013012-3 Datasheet, TE Connectivity AMP Connectors Distributor | |
2013012-3 Details Description
