Grayhill, Inc. 26AS22-01B16S
- Mfg. Part Number
- 26AS22-01B16S
- Manufacturer
- Grayhill, Inc.
- Product Category
- Encoders
- Brief Description
- ENCODER ROTARY 16POS PCB
- Datasheet Download
- 26AS22-01B16S.pdf
Availability of 26AS22-01B16S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 23.66120
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 26AS22-01B16S, we specialize in Grayhill, Inc. all series electronic components. 26AS22-01B16S can be shipped within 24 hours after order. If you have any demands for 26AS22-01B16S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 26AS22-01B16S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
26AS22-01B16S
| Internal Part Number | EIS-26AS22-01B16S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Sensors, Transducers | |
| Family | Encoders | |
| Series | 26 | |
| Encoder Type | Mechanical | |
| Output Type | Hexadecimal (Absolute) | |
| Pulses per Revolution | 16 | |
| Voltage - Supply | - | |
| Actuator Type | 1/8" Dia Flatted End | |
| Detent | Yes | |
| Built in Switch | No | |
| Mounting Type | Panel, PCB Through Hole | |
| Orientation | Vertical | |
| Termination Style | PC Pin | |
| Rotational Life (Cycles Min) | 25K | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 26AS22-01B16S | |
| Related Links | 26AS22, 26AS22-01B16S Datasheet, Grayhill, Inc. Distributor | |
26AS22-01B16S Details Description
