Hammond Manufacturing 270AX
- Mfg. Part Number
- 270AX
- Manufacturer
- Hammond Manufacturing
- Product Category
- Power Transformers
- Brief Description
- XFRMR LAMINATED 42VA CHAS MOUNT
- Datasheet Download
- 270AX.pdf
Availability of 270AX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 51.89000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 270AX, we specialize in Hammond Manufacturing all series electronic components. 270AX can be shipped within 24 hours after order. If you have any demands for 270AX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 270AX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
270AX
| Internal Part Number | EIS-270AX | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Transformers | |
| Family | Power Transformers | |
| Series | 270 | |
| Type | Laminated Core | |
| Voltage - Primary | 115V | |
| Voltage - Secondary (Full Load) | 480V, 6.3V | |
| Current - Output (Max) | 58mA, 2.5A | |
| Primary Winding(s) | Single | |
| Secondary Winding(s) | Dual | |
| Center Tap | Yes | |
| Power - Max | 42 VA | |
| Mounting Type | Chassis Mount | |
| Termination Style | Wire Leads | |
| Size / Dimension | 55.63mm L x 63.50mm W | |
| Height - Seated (Max) | 66.80mm | |
| Voltage - Isolation | 2000Vrms | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 270AX | |
| Related Links | 27, 270AX Datasheet, Hammond Manufacturing Distributor | |
270AX Details Description
