Honeywell Sensing and Productivity Solutions 2DM438
- Mfg. Part Number
- 2DM438
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH SNAP MOM DPDT 10A QC
- Datasheet Download
- 2DM438.pdf
Availability of 2DM438
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.42820
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2DM438, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. 2DM438 can be shipped within 24 hours after order. If you have any demands for 2DM438, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2DM438 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2DM438
| Internal Part Number | EIS-2DM438 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | DM | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-On-Mom | |
| Current Rating | 10A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Push-Pull Plunger | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Quick Connect - 0.187" (4.7mm) | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 680gf | |
| Release Force | - | |
| Pretravel | - | |
| Differential Travel | - | |
| Overtravel | 0.590" (15.0mm) | |
| Operating Position | 0.745" (18.9mm) | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | - | |
| Operating Temperature | -37°C ~ 82°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2DM438 | |
| Related Links | 2DM, 2DM438 Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
2DM438 Details Description
