Panasonic Electronic Components 2SC5846G0L
- Mfg. Part Number
- 2SC5846G0L
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Transistors (BJT) - Single
- Brief Description
- TRANS NPN 50V 0.1A SSSMINI3P
- Datasheet Download
- 2SC5846G0L.pdf
Availability of 2SC5846G0L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2SC5846G0L, we specialize in Panasonic Electronic Components all series electronic components. 2SC5846G0L can be shipped within 24 hours after order. If you have any demands for 2SC5846G0L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2SC5846G0L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2SC5846G0L
| Internal Part Number | EIS-2SC5846G0L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Transistor Type | NPN | |
| Current - Collector (Ic) (Max) | 100mA | |
| Voltage - Collector Emitter Breakdown (Max) | 50V | |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 10mA, 100mA | |
| Current - Collector Cutoff (Max) | 100µA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 180 @ 2mA, 10V | |
| Power - Max | 100mW | |
| Frequency - Transition | 100MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-723 | |
| Supplier Device Package | SSSMini3-F2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2SC5846G0L | |
| Related Links | 2SC58, 2SC5846G0L Datasheet, Panasonic Electronic Components Distributor | |
2SC5846G0L Details Description
