Microsemi Commercial Components 3EZ22D5E3/TR8
- Mfg. Part Number
- 3EZ22D5E3/TR8
- Manufacturer
- Microsemi Commercial Components
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 22V 3W DO204AL
- Datasheet Download
- 3EZ22D5E3/TR8.pdf
Availability of 3EZ22D5E3/TR8
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.72500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 3EZ22D5E3/TR8, we specialize in Microsemi Commercial Components all series electronic components. 3EZ22D5E3/TR8 can be shipped within 24 hours after order. If you have any demands for 3EZ22D5E3/TR8, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 3EZ22D5E3/TR8 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
3EZ22D5E3/TR8
| Internal Part Number | EIS-3EZ22D5E3/TR8 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,500 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 22V | |
| Tolerance | ±5% | |
| Power - Max | 3W | |
| Impedance (Max) (Zzt) | 8 Ohm | |
| Current - Reverse Leakage @ Vr | 500nA @ 16.7V | |
| Voltage - Forward (Vf) (Max) @ If | 1.2V @ 200mA | |
| Operating Temperature | -65°C ~ 150°C | |
| Mounting Type | Through Hole | |
| Package / Case | DO-204AL, DO-41, Axial | |
| Supplier Device Package | DO-204AL (DO-41) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 3EZ22D5E3/TR8 | |
| Related Links | 3EZ22D, 3EZ22D5E3/TR8 Datasheet, Microsemi Commercial Components Distributor | |
3EZ22D5E3/TR8 Details Description
