Grayhill, Inc. 44A30-06-2-05S
- Mfg. Part Number
- 44A30-06-2-05S
- Manufacturer
- Grayhill, Inc.
- Product Category
- Rotary Switches
- Brief Description
- SWITCH ROTARY DP5T
- Datasheet Download
- 44A30-06-2-05S.pdf
Availability of 44A30-06-2-05S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 105.15500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 44A30-06-2-05S, we specialize in Grayhill, Inc. all series electronic components. 44A30-06-2-05S can be shipped within 24 hours after order. If you have any demands for 44A30-06-2-05S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 44A30-06-2-05S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
44A30-06-2-05S
| Internal Part Number | EIS-44A30-06-2-05S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Other | Multiple Devices Plating Material 30/Jan/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rotary Switches | |
| Series | 44 | |
| Number of Positions | 5 | |
| Index Stops | Fixed | |
| Number of Decks | 6 | |
| Number of Poles per Deck | 2 | |
| Circuit per Deck | DP5T | |
| Contact Timing | Shorting (MBB) | |
| Current Rating | 1A (AC/DC) | |
| Voltage Rating - AC | 115V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Flatted (6.35mm Dia) | |
| Actuator Length | 11.10mm | |
| Angle of Throw | 30° | |
| Contact Material | Silver Alloy | |
| Contact Finish | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Features | - | |
| Depth Behind Panel | 76.33mm | |
| Panel Cutout Dimensions | - | |
| Operating Force, Torque | 8 ~ 115 in-oz | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 44A30-06-2-05S | |
| Related Links | 44A30-0, 44A30-06-2-05S Datasheet, Grayhill, Inc. Distributor | |
