TE Connectivity Measurement Specialties 4525DO-DS5AI015DP
- Mfg. Part Number
- 4525DO-DS5AI015DP
- Manufacturer
- TE Connectivity Measurement Specialties
- Product Category
- Pressure Sensors, Transducers
- Brief Description
- SENSOR DIFF PRESS 15PSI 8DIP PCB
- Datasheet Download
- 4525DO-DS5AI015DP.pdf
Availability of 4525DO-DS5AI015DP
Available Quantity
5082 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 21.48375
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 4525DO-DS5AI015DP, we specialize in TE Connectivity Measurement Specialties all series electronic components. 4525DO-DS5AI015DP can be shipped within 24 hours after order. If you have any demands for 4525DO-DS5AI015DP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 4525DO-DS5AI015DP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
4525DO-DS5AI015DP
| Internal Part Number | EIS-4525DO-DS5AI015DP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | MS45xx Series | |
| Featured Product | MS45xx Series Pressure Sensors | |
| Standard Package | 10 | |
| Category | Sensors, Transducers | |
| Family | Pressure Sensors, Transducers | |
| Series | MS4525DO | |
| Pressure Type | Differential | |
| Operating Pressure | 15 PSI (103.42 kPa) | |
| Output Type | I²C | |
| Output | 14 b | |
| Accuracy | ±0.25% | |
| Voltage - Supply | 5V | |
| Port Size | Male - 0.14" (3.56mm) Tube, Dual | |
| Port Style | Barbed | |
| Features | Temperature Compensated | |
| Termination Style | PC Pin | |
| Maximum Pressure | 45 PSI (310.26 kPa) | |
| Operating Temperature | -25°C ~ 105°C | |
| Package / Case | 8-DIP Module | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 4525DO-DS5AI015DP | |
| Related Links | 4525DO-D, 4525DO-DS5AI015DP Datasheet, TE Connectivity Measurement Specialties Distributor | |
