Bourns Inc. 4816P-T02-683LF
- Mfg. Part Number
- 4816P-T02-683LF
- Manufacturer
- Bourns Inc.
- Product Category
- Resistor Networks, Arrays
- Brief Description
- RES ARRAY 15 RES 68K OHM 16SOIC
- Datasheet Download
- 4816P-T02-683LF.pdf
Availability of 4816P-T02-683LF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.51200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 4816P-T02-683LF, we specialize in Bourns Inc. all series electronic components. 4816P-T02-683LF can be shipped within 24 hours after order. If you have any demands for 4816P-T02-683LF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 4816P-T02-683LF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
4816P-T02-683LF
| Internal Part Number | EIS-4816P-T02-683LF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | 4400,4800 Model Terminal Finish Aug/2007 41xx,43xx,44x,48xx Model May 2012 | |
| Standard Package | 50 | |
| Category | Resistors | |
| Family | Resistor Networks, Arrays | |
| Series | 4800P | |
| Packaging | Tube | |
| Circuit Type | Bussed | |
| Resistance (Ohms) | 68k | |
| Tolerance | ±2% | |
| Number of Resistors | 15 | |
| Number of Pins | 16 | |
| Power Per Element | 80mW | |
| Temperature Coefficient | ±100ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | Automotive AEC-Q200 | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SOIC (0.220", 5.59mm Width) | |
| Supplier Device Package | 16-SOM | |
| Size / Dimension | 0.440" L x 0.220" W (11.18mm x 5.59mm) | |
| Height | 0.085" (2.16mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 4816P-T02-683LF | |
| Related Links | 4816P-T, 4816P-T02-683LF Datasheet, Bourns Inc. Distributor | |
4816P-T02-683LF Details Description
