Grayhill, Inc. 48ASDP1S3M1QAT
- Mfg. Part Number
- 48ASDP1S3M1QAT
- Manufacturer
- Grayhill, Inc.
- Product Category
- Slide Switches
- Brief Description
- SWITCH SLIDE DPDT 5A 125V
- Datasheet Download
- 48ASDP1S3M1QAT.pdf
Availability of 48ASDP1S3M1QAT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.40000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 48ASDP1S3M1QAT, we specialize in Grayhill, Inc. all series electronic components. 48ASDP1S3M1QAT can be shipped within 24 hours after order. If you have any demands for 48ASDP1S3M1QAT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 48ASDP1S3M1QAT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
48ASDP1S3M1QAT
| Internal Part Number | EIS-48ASDP1S3M1QAT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Compliance Status by Product Type | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Slide Switches | |
| Series | 48A | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Contact Timing | Not Specified | |
| Switch Function | On-On | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Standard | |
| Actuator Length | 9.40mm | |
| Contact Material | Copper Alloy | |
| Contact Finish | Silver | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Polyamide (PA), Nylon | |
| Switch Travel | 2.16mm | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | - | |
| Electrical Life | 30,000 Cycles | |
| Operating Force | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 48ASDP1S3M1QAT | |
| Related Links | 48ASDP1, 48ASDP1S3M1QAT Datasheet, Grayhill, Inc. Distributor | |
