Silicon Labs 511SBA-CAAG
- Mfg. Part Number
- 511SBA-CAAG
- Manufacturer
- Silicon Labs
- Product Category
- Programmable Oscillators
- Brief Description
- OSC PROG 1.8V CMOS 25PPM 5X7MM
- Datasheet Download
- 511SBA-CAAG.pdf
Availability of 511SBA-CAAG
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.82263
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 511SBA-CAAG, we specialize in Silicon Labs all series electronic components. 511SBA-CAAG can be shipped within 24 hours after order. If you have any demands for 511SBA-CAAG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 511SBA-CAAG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
511SBA-CAAG
| Internal Part Number | EIS-511SBA-CAAG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Clock Tree Timing Solutions | |
| Featured Product | Si510 and Si511 Low Jitter Xos | |
| Standard Package | 1 | |
| Category | Crystals and Oscillators | |
| Family | Programmable Oscillators | |
| Series | Si511 | |
| Packaging | Tray | |
| Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) | |
| Available Frequency Range | 170MHz ~ 250MHz | |
| Function | Enable/Disable | |
| Output | CMOS, Dual (Complimentary) | |
| Voltage - Supply | 1.8V | |
| Frequency Stability | ±25ppm | |
| Operating Temperature | -40°C ~ 85°C | |
| Spread Spectrum Bandwidth | - | |
| Current - Supply (Max) | 26mA | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-SMD, No Lead (DFN, LCC) | |
| Height | 0.071" (1.80mm) | |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Current - Supply (Disable) (Max) | 18mA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 511SBA-CAAG | |
| Related Links | 511SB, 511SBA-CAAG Datasheet, Silicon Labs Distributor | |
511SBA-CAAG Details Description
