Micro Commercial Components (MCC) 5KP48A-TP
- Mfg. Part Number
- 5KP48A-TP
- Manufacturer
- Micro Commercial Components (MCC)
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 48VWM 77.4VC R6
- Datasheet Download
- 5KP48A-TP.pdf
Availability of 5KP48A-TP
Available Quantity
5520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.72000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 5KP48A-TP, we specialize in Micro Commercial Components (MCC) all series electronic components. 5KP48A-TP can be shipped within 24 hours after order. If you have any demands for 5KP48A-TP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 5KP48A-TP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
5KP48A-TP
| Internal Part Number | EIS-5KP48A-TP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | TVS Breakdown Voltage 15/May/2013 | |
| Standard Package | 500 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 48V | |
| Voltage - Breakdown (Min) | 53.3V | |
| Voltage - Clamping (Max) @ Ipp | 77.4V | |
| Current - Peak Pulse (10/1000µs) | - | |
| Power - Peak Pulse | 5000W (5kW) | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 175°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | R6, Axial | |
| Supplier Device Package | R-6 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 5KP48A-TP | |
| Related Links | 5KP4, 5KP48A-TP Datasheet, Micro Commercial Components (MCC) Distributor | |
5KP48A-TP Details Description
