Grayhill, Inc. 71AD30-06-2-AJN
- Mfg. Part Number
- 71AD30-06-2-AJN
- Manufacturer
- Grayhill, Inc.
- Product Category
- Rotary Switches
- Brief Description
- SWITCH ROTARY
- Datasheet Download
- 71AD30-06-2-AJN.pdf
Availability of 71AD30-06-2-AJN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 44.51880
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 71AD30-06-2-AJN, we specialize in Grayhill, Inc. all series electronic components. 71AD30-06-2-AJN can be shipped within 24 hours after order. If you have any demands for 71AD30-06-2-AJN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 71AD30-06-2-AJN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
71AD30-06-2-AJN
| Internal Part Number | EIS-71AD30-06-2-AJN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Other | Multiple Devices Plating Material 30/Jan/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rotary Switches | |
| Series | 71 | |
| Number of Positions | 2 ~ 6 | |
| Index Stops | Adjustable | |
| Number of Decks | 6 | |
| Number of Poles per Deck | 2 | |
| Circuit per Deck | DP6T | |
| Contact Timing | Non-Shorting (BBM) | |
| Current Rating | 250mA (AC/DC) | |
| Voltage Rating - AC | 115V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Flatted (3.17mm Dia) | |
| Actuator Length | 9.53mm | |
| Angle of Throw | 30° | |
| Contact Material | Silver Alloy | |
| Contact Finish | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Features | - | |
| Depth Behind Panel | 54.13mm | |
| Panel Cutout Dimensions | - | |
| Operating Force, Torque | 4 ~ 32 in-oz | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 71AD30-06-2-AJN | |
| Related Links | 71AD30-, 71AD30-06-2-AJN Datasheet, Grayhill, Inc. Distributor | |
