C&K Components 7201P4D9V31GE
- Mfg. Part Number
- 7201P4D9V31GE
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT 5A 120V
- Datasheet Download
- 7201P4D9V31GE.pdf
Availability of 7201P4D9V31GE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.05000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7201P4D9V31GE, we specialize in C&K Components all series electronic components. 7201P4D9V31GE can be shipped within 24 hours after order. If you have any demands for 7201P4D9V31GE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7201P4D9V31GE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7201P4D9V31GE
| Internal Part Number | EIS-7201P4D9V31GE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Flat Anti-Rotation | |
| Actuator Length | 8.13mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 100,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7201P4D9V31GE | |
| Related Links | 7201P4, 7201P4D9V31GE Datasheet, C&K Components Distributor | |
7201P4D9V31GE Details Description
