C&K Components 7301L2PD9AV2QE
- Mfg. Part Number
- 7301L2PD9AV2QE
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE 3PDT 5A 120V
- Datasheet Download
- 7301L2PD9AV2QE.pdf
Availability of 7301L2PD9AV2QE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 13.82200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7301L2PD9AV2QE, we specialize in C&K Components all series electronic components. 7301L2PD9AV2QE can be shipped within 24 hours after order. If you have any demands for 7301L2PD9AV2QE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7301L2PD9AV2QE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7301L2PD9AV2QE
| Internal Part Number | EIS-7301L2PD9AV2QE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | 3PDT | |
| Switch Function | On-On | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Anti-Rotation | |
| Actuator Length | 15.75mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole, Right Angle, Vertical | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 100,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7301L2PD9AV2QE | |
| Related Links | 7301L2P, 7301L2PD9AV2QE Datasheet, C&K Components Distributor | |
7301L2PD9AV2QE Details Description
