Fairchild Semiconductor 74ACTQ543SCX
- Mfg. Part Number
- 74ACTQ543SCX
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Logic - Buffers, Drivers, Receivers, Transceivers
- Brief Description
- IC REGISTERED TXRX 3ST 8B 24SOIC
- Datasheet Download
- 74ACTQ543SCX.pdf
Availability of 74ACTQ543SCX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 74ACTQ543SCX, we specialize in Fairchild Semiconductor all series electronic components. 74ACTQ543SCX can be shipped within 24 hours after order. If you have any demands for 74ACTQ543SCX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 74ACTQ543SCX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
74ACTQ543SCX
| Internal Part Number | EIS-74ACTQ543SCX | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Buffers, Drivers, Receivers, Transceivers | |
| Series | 74ACTQ | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | Registered Transceiver, Non-Inverting | |
| Number of Elements | 1 | |
| Number of Bits per Element | 8 | |
| Current - Output High, Low | 24mA, 24mA | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 24-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 74ACTQ543SCX | |
| Related Links | 74ACTQ, 74ACTQ543SCX Datasheet, Fairchild Semiconductor Distributor | |
74ACTQ543SCX Details Description
