NXP Semiconductors/Freescale Semiconductor, Inc. 74LVC02ADB,112
- Mfg. Part Number
- 74LVC02ADB,112
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Logic - Gates and Inverters
- Brief Description
- IC GATE NOR 4CH 2-INP 14-SSOP
- Datasheet Download
- 74LVC02ADB,112.pdf
Availability of 74LVC02ADB,112
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.17000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 74LVC02ADB,112, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. 74LVC02ADB,112 can be shipped within 24 hours after order. If you have any demands for 74LVC02ADB,112, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 74LVC02ADB,112 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
74LVC02ADB,112
| Internal Part Number | EIS-74LVC02ADB,112 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Logic Packages | |
| Standard Package | 78 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters | |
| Series | 74LVC | |
| Packaging | Tube | |
| Logic Type | NOR Gate | |
| Number of Circuits | 4 | |
| Number of Inputs | 2 | |
| Features | - | |
| Voltage - Supply | 1.2 V ~ 3.6 V | |
| Current - Quiescent (Max) | 40µA | |
| Current - Output High, Low | 24mA, 24mA | |
| Logic Level - Low | 0.7 V ~ 0.8 V | |
| Logic Level - High | 1.7 V ~ 2 V | |
| Max Propagation Delay @ V, Max CL | 2.2ns @ 3.3V, 50pF | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | 14-SSOP | |
| Package / Case | 14-SSOP (0.209", 5.30mm Width) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 74LVC02ADB,112 | |
| Related Links | 74LVC02, 74LVC02ADB,112 Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
74LVC02ADB,112 Details Description
