Fairchild Semiconductor 74OL6000SD
- Mfg. Part Number
- 74OL6000SD
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Optoisolators - Logic Output
- Brief Description
- OPTOISO 5.3KV PUSH PULL 6SOIC
- Datasheet Download
- 74OL6000SD.pdf
Availability of 74OL6000SD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 74OL6000SD, we specialize in Fairchild Semiconductor all series electronic components. 74OL6000SD can be shipped within 24 hours after order. If you have any demands for 74OL6000SD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 74OL6000SD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
74OL6000SD
| Internal Part Number | EIS-74OL6000SD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Optoisolators - Logic Output | |
| Series | OPTOLOGIC™ OPTOPLANAR® | |
| Packaging | Tape & Reel (TR) | |
| Number of Channels | 1 | |
| Inputs - Side 1/Side 2 | 1/0 | |
| Voltage - Isolation | 5300Vrms | |
| Common Mode Transient Immunity (Min) | 5kV/µs | |
| Input Type | Logic | |
| Output Type | Push-Pull, Totem Pole | |
| Current - Output / Channel | 40mA | |
| Data Rate | 15MBd | |
| Propagation Delay tpLH / tpHL (Max) | 100ns, 100ns | |
| Rise / Fall Time (Typ) | 45ns, 5ns | |
| Voltage - Forward (Vf) (Typ) | - | |
| Current - DC Forward (If) (Max) | - | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-SOIC | |
| Supplier Device Package | 6-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 74OL6000SD | |
| Related Links | 74OL6, 74OL6000SD Datasheet, Fairchild Semiconductor Distributor | |
74OL6000SD Details Description
