Mill-Max 801-43-009-40-002000
- Mfg. Part Number
- 801-43-009-40-002000
- Manufacturer
- Mill-Max
- Product Category
- Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets
- Brief Description
- CONN SOCKET 9POS SIP .100 R/ANG
- Datasheet Download
- 801-43-009-40-002000.pdf
Availability of 801-43-009-40-002000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.56139
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 801-43-009-40-002000, we specialize in Mill-Max all series electronic components. 801-43-009-40-002000 can be shipped within 24 hours after order. If you have any demands for 801-43-009-40-002000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 801-43-009-40-002000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
801-43-009-40-002000
| Internal Part Number | EIS-801-43-009-40-002000 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Board to Board Connectors | |
| Standard Package | 22 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets | |
| Series | 801 | |
| Packaging | Bulk | |
| Connector Type | Receptacle | |
| Number of Positions | 9 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Height Stacking (Mating) | - | |
| Height Above Board | 0.100" (2.54mm) | |
| Mounting Type | Surface Mount, Right Angle | |
| Termination | Solder | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Features | - | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 801-43-009-40-002000 | |
| Related Links | 801-43-009, 801-43-009-40-002000 Datasheet, Mill-Max Distributor | |
