Omron Automation & Safety A16L-JRM-12D-1
- Mfg. Part Number
- A16L-JRM-12D-1
- Manufacturer
- Omron Automation & Safety
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON SPDT 5A 125V
- Datasheet Download
- A16L-JRM-12D-1.pdf
Availability of A16L-JRM-12D-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 31.27000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A16L-JRM-12D-1, we specialize in Omron Automation & Safety all series electronic components. A16L-JRM-12D-1 can be shipped within 24 hours after order. If you have any demands for A16L-JRM-12D-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A16L-JRM-12D-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A16L-JRM-12D-1
| Internal Part Number | EIS-A16L-JRM-12D-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Multiple Devices Nameplate May/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | A16 | |
| Packaging | Bulk | |
| Type | Standard, Illuminated | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Rectangular, Button | |
| Color - Actuator/Cap | Red | |
| Illumination Type, Color | LED, Red | |
| Illumination Voltage (Nominal) | 12 VDC | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | IP40 | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 16.00mm Dia | |
| Operating Temperature | -10°C ~ 55°C | |
| Mechanical Life | 2,000,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A16L-JRM-12D-1 | |
| Related Links | A16L-JR, A16L-JRM-12D-1 Datasheet, Omron Automation & Safety Distributor | |
A16L-JRM-12D-1 Details Description
