Hirose Electric Co Ltd A2-12PA-2.54DSA(71)
- Mfg. Part Number
- A2-12PA-2.54DSA(71)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- HEADER 12POS 2.54MM
- Datasheet Download
- A2-12PA-2.54DSA(71).pdf
Availability of A2-12PA-2.54DSA(71)
Available Quantity
5022 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.92400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A2-12PA-2.54DSA(71), we specialize in Hirose Electric Co Ltd all series electronic components. A2-12PA-2.54DSA(71) can be shipped within 24 hours after order. If you have any demands for A2-12PA-2.54DSA(71), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A2-12PA-2.54DSA(71) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A2-12PA-2.54DSA(71)
| Internal Part Number | EIS-A2-12PA-2.54DSA(71) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | A2 | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded | |
| Number of Positions | 12 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | 0.236" (6.00mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 8µin (0.20µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A2-12PA-2.54DSA(71) | |
| Related Links | A2-12PA-2, A2-12PA-2.54DSA(71) Datasheet, Hirose Electric Co Ltd Distributor | |
A2-12PA-2.54DSA(71) Details Description
