Omron Automation & Safety A22-DB-02M
- Mfg. Part Number
- A22-DB-02M
- Manufacturer
- Omron Automation & Safety
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSH DPST-NC 10A 110V
- Datasheet Download
- A22-DB-02M.pdf
Availability of A22-DB-02M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A22-DB-02M, we specialize in Omron Automation & Safety all series electronic components. A22-DB-02M can be shipped within 24 hours after order. If you have any demands for A22-DB-02M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A22-DB-02M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A22-DB-02M
| Internal Part Number | EIS-A22-DB-02M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | A22x,M22,A22-x Series Aug/2013 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | A22 | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | DPST-NC | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC/DC) | |
| Voltage Rating - AC | 110V | |
| Voltage Rating - DC | 24V | |
| Actuator Type | Square, Button, Full Guard | |
| Color - Actuator/Cap | Black | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Screw Terminal | |
| Ingress Protection | IP65 - Dust Tight, Oil and Water Resistant | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 22.30mm Dia | |
| Operating Temperature | -20°C ~ 70°C | |
| Mechanical Life | 5,000,000 Cycles | |
| Electrical Life | 500,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A22-DB-02M | |
| Related Links | A22-D, A22-DB-02M Datasheet, Omron Automation & Safety Distributor | |
A22-DB-02M Details Description
