Microsemi SoC A2F200M3F-PQG208I
- Mfg. Part Number
- A2F200M3F-PQG208I
- Manufacturer
- Microsemi SoC
- Product Category
- Embedded - System On Chip (SoC)
- Brief Description
- IC FPGA 200K GATES 256KB 208PQFP
- Datasheet Download
- A2F200M3F-PQG208I.pdf
Availability of A2F200M3F-PQG208I
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 31.82000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A2F200M3F-PQG208I, we specialize in Microsemi SoC all series electronic components. A2F200M3F-PQG208I can be shipped within 24 hours after order. If you have any demands for A2F200M3F-PQG208I, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A2F200M3F-PQG208I Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A2F200M3F-PQG208I
| Internal Part Number | EIS-A2F200M3F-PQG208I | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Other | SmartFusion Fixes 11/Mar/2015 | |
| Standard Package | 24 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - System On Chip (SoC) | |
| Series | SmartFusion® | |
| Packaging | Tray | |
| Architecture | MCU, FPGA | |
| Core Processor | ARM® Cortex®-M3 | |
| MCU Flash | 256KB | |
| MCU RAM | 64KB | |
| Peripherals | DMA, POR, WDT | |
| Connectivity | EBI/EMI, Ethernet, I²C, SPI, UART/USART | |
| Speed | 80MHz | |
| Primary Attributes | ProASIC®3 FPGA, 200K Gates, 4608 D-Flip-Flops | |
| Operating Temperature | -40°C ~ 100°C | |
| Package / Case | 208-BFQFP | |
| Supplier Device Package | 208-PQFP (28x28) | |
| Number of I/O | MCU - 22, FPGA - 66 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A2F200M3F-PQG208I | |
| Related Links | A2F200M3, A2F200M3F-PQG208I Datasheet, Microsemi SoC Distributor | |
A2F200M3F-PQG208I Details Description
