Allegro MicroSystems, LLC A3941KLPTR-T
- Mfg. Part Number
- A3941KLPTR-T
- Manufacturer
- Allegro MicroSystems, LLC
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOSFET FULL BRDG AUTO 28TSSOP
- Datasheet Download
- A3941KLPTR-T.pdf
Availability of A3941KLPTR-T
Available Quantity
13020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.76400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A3941KLPTR-T, we specialize in Allegro MicroSystems, LLC all series electronic components. A3941KLPTR-T can be shipped within 24 hours after order. If you have any demands for A3941KLPTR-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A3941KLPTR-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A3941KLPTR-T
| Internal Part Number | EIS-A3941KLPTR-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 4,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | - | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Controller - Commutation, Direction Management | |
| Output Configuration | Pre-Driver - Half Bridge (2) | |
| Interface | PWM | |
| Technology | Power MOSFET | |
| Step Resolution | - | |
| Applications | Automotive | |
| Current - Output | - | |
| Voltage - Supply | 5.5 V ~ 50 V | |
| Voltage - Load | - | |
| Operating Temperature | -40°C ~ 150°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad | |
| Supplier Device Package | 28-TSSOP-EP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A3941KLPTR-T | |
| Related Links | A3941K, A3941KLPTR-T Datasheet, Allegro MicroSystems, LLC Distributor | |
