Omron Automation & Safety A3AT-90L1-00G
- Mfg. Part Number
- A3AT-90L1-00G
- Manufacturer
- Omron Automation & Safety
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSH SPST-NO 6A 125V
- Datasheet Download
- A3AT-90L1-00G.pdf
Availability of A3AT-90L1-00G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.68000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A3AT-90L1-00G, we specialize in Omron Automation & Safety all series electronic components. A3AT-90L1-00G can be shipped within 24 hours after order. If you have any demands for A3AT-90L1-00G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A3AT-90L1-00G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A3AT-90L1-00G
| Internal Part Number | EIS-A3AT-90L1-00G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | A3A CCC Marking Nov/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | A3A | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | SPST-NO | |
| Switch Function | Off-On | |
| Current Rating | 6A (AC), 4A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Round, Button | |
| Color - Actuator/Cap | Green | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Rear | |
| Termination Style | Solder Lug | |
| Ingress Protection | IP00 | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 11.50mm Dia | |
| Operating Temperature | -10°C ~ 55°C | |
| Mechanical Life | 50,000 Cycles | |
| Electrical Life | 50,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A3AT-90L1-00G | |
| Related Links | A3AT-9, A3AT-90L1-00G Datasheet, Omron Automation & Safety Distributor | |
A3AT-90L1-00G Details Description
