Switchcraft Inc. AA3MB
- Mfg. Part Number
- AA3MB
- Manufacturer
- Switchcraft Inc.
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT MALE 3POS INLINE XLR
- Datasheet Download
- AA3MB.pdf
Availability of AA3MB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AA3MB, we specialize in Switchcraft Inc. all series electronic components. AA3MB can be shipped within 24 hours after order. If you have any demands for AA3MB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AA3MB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AA3MB
| Internal Part Number | EIS-AA3MB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Switchcraft RoHS Info | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | Q-G® AA | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Male Pins | |
| Number of Positions | 3 | |
| Shell Size - Insert | XLR | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Solder | |
| Fastening Type | Latch Holder | |
| Orientation | Keyed | |
| Ingress Protection | - | |
| Shell Material, Finish | Zinc Die Cast, Black Plated | |
| Contact Finish | Silver | |
| Features | Cable Clamp, Strain Relief | |
| Contact Finish Thickness | - | |
| Current Rating | 15A | |
| Voltage - Rated | 125VAC | |
| Operating Temperature | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AA3MB | |
| Related Links | AA, AA3MB Datasheet, Switchcraft Inc. Distributor | |
AA3MB Details Description
