Analog AD7564ARSZ-BREEL
- Mfg. Part Number
- AD7564ARSZ-BREEL
- Manufacturer
- Analog
- Product Category
- Data Acquisition - Digital to Analog Converters (DAC)
- Brief Description
- IC DAC 12BIT QUAD 3.3V LP 28SSOP
- Datasheet Download
- AD7564ARSZ-BREEL.pdf
Availability of AD7564ARSZ-BREEL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.22755
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AD7564ARSZ-BREEL, we specialize in Analog all series electronic components. AD7564ARSZ-BREEL can be shipped within 24 hours after order. If you have any demands for AD7564ARSZ-BREEL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AD7564ARSZ-BREEL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AD7564ARSZ-BREEL
| Internal Part Number | EIS-AD7564ARSZ-BREEL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Data Converter Fundamentals DAC Architectures Five Things to Know About DACs Part 1: Resolution vs. Accuracy Five Things to Know About DACs Part 2: Total Unadjusted Error (TUE) Five Things to Know About DACs Part 5: Dynamic Performance Five Things to Know About DACs Part 4: Buffering | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Digital to Analog Converters (DAC) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Settling Time | 550ns | |
| Number of Bits | 12 | |
| Data Interface | Serial | |
| Number of Converters | 4 | |
| Voltage Supply Source | Single Supply | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 28-SSOP | |
| Number of Outputs and Type | 8 Current | |
| Sampling Rate (Per Second) | 1.8M | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AD7564ARSZ-BREEL | |
| Related Links | AD7564AR, AD7564ARSZ-BREEL Datasheet, Analog Distributor | |
