Analog AD8422ARMZ-RL
- Mfg. Part Number
- AD8422ARMZ-RL
- Manufacturer
- Analog
- Product Category
- Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- Brief Description
- IC OPAMP INSTR 2.2MHZ RRO 8MSOP
- Datasheet Download
- AD8422ARMZ-RL.pdf
Availability of AD8422ARMZ-RL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.75443
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AD8422ARMZ-RL, we specialize in Analog all series electronic components. AD8422ARMZ-RL can be shipped within 24 hours after order. If you have any demands for AD8422ARMZ-RL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AD8422ARMZ-RL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AD8422ARMZ-RL
| Internal Part Number | EIS-AD8422ARMZ-RL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Pressure Transmitter Solutions Electromagnetic Flow Meter Solutions Programmable Logic Controllers (PLCs) Solutions | |
| PCN Design/Specification | AD8422 Die/Datasheet Update 15/Dec/2014 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Amplifier Type | Instrumentation | |
| Number of Circuits | 1 | |
| Output Type | Rail-to-Rail | |
| Slew Rate | 0.8 V/µs | |
| Gain Bandwidth Product | - | |
| -3db Bandwidth | 2.2MHz | |
| Current - Input Bias | 500pA | |
| Voltage - Input Offset | 70µV | |
| Current - Supply | 300µA | |
| Current - Output / Channel | 20mA | |
| Voltage - Supply, Single/Dual (±) | 3.6 V ~ 36 V, ±1.8 V ~ 18 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | |
| Supplier Device Package | 8-MSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AD8422ARMZ-RL | |
| Related Links | AD8422, AD8422ARMZ-RL Datasheet, Analog Distributor | |
AD8422ARMZ-RL Details Description
