Analog ADP2371ACPZ-1.2-R7
- Mfg. Part Number
- ADP2371ACPZ-1.2-R7
- Manufacturer
- Analog
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BCK 1.2V 0.8A SYNC 8LFCSP
- Datasheet Download
- ADP2371ACPZ-1.2-R7.pdf
Availability of ADP2371ACPZ-1.2-R7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.86200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADP2371ACPZ-1.2-R7, we specialize in Analog all series electronic components. ADP2371ACPZ-1.2-R7 can be shipped within 24 hours after order. If you have any demands for ADP2371ACPZ-1.2-R7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADP2371ACPZ-1.2-R7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADP2371ACPZ-1.2-R7
| Internal Part Number | EIS-ADP2371ACPZ-1.2-R7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | LFCSP 2x3,3x3 Assembly Test Site Transfer 18/Oct/2013 Assembly/Test Site Revision B 28/Apr/2014 Assembly/Test Site Revision C 06/Aug/2014 | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Fixed | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 3.2V | |
| Voltage - Input (Max) | 15V | |
| Voltage - Output (Min/Fixed) | 1.2V | |
| Voltage - Output (Max) | - | |
| Current - Output | 800mA | |
| Frequency - Switching | 600kHz ~ 1.2MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-WFDFN Exposed Pad, CSP | |
| Supplier Device Package | 8-LFCSP-WD (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADP2371ACPZ-1.2-R7 | |
| Related Links | ADP2371AC, ADP2371ACPZ-1.2-R7 Datasheet, Analog Distributor | |
ADP2371ACPZ-1.2-R7 Details Description
