Analog ADSP-BF504KCPZ-4
- Mfg. Part Number
- ADSP-BF504KCPZ-4
- Manufacturer
- Analog
- Product Category
- Embedded - DSP (Digital Signal Processors)
- Brief Description
- IC CCD SIGNAL PROCESSOR 88LFCSP
- Datasheet Download
- ADSP-BF504KCPZ-4.pdf
Availability of ADSP-BF504KCPZ-4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.10375
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADSP-BF504KCPZ-4, we specialize in Analog all series electronic components. ADSP-BF504KCPZ-4 can be shipped within 24 hours after order. If you have any demands for ADSP-BF504KCPZ-4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADSP-BF504KCPZ-4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADSP-BF504KCPZ-4
| Internal Part Number | EIS-ADSP-BF504KCPZ-4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Renewable Energy—Solar PV Solutions | |
| PCN Design/Specification | ADSP-BF504,6 Datasheet Update 19/May/2014 | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - DSP (Digital Signal Processors) | |
| Series | Blackfin® | |
| Packaging | Tray | |
| Type | Fixed Point | |
| Interface | CAN, EBI/EMI, I²C, IrDA, PPI, SPI, SPORT, UART/USART | |
| Clock Rate | 400MHz | |
| Non-Volatile Memory | External | |
| On-Chip RAM | 68kB | |
| Voltage - I/O | 1.8V, 2.5V, 3.3V | |
| Voltage - Core | 1.31V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 88-VFQFN Exposed Pad, CSP | |
| Supplier Device Package | 88-LFCSP-VQ (12x12) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADSP-BF504KCPZ-4 | |
| Related Links | ADSP-BF5, ADSP-BF504KCPZ-4 Datasheet, Analog Distributor | |
ADSP-BF504KCPZ-4 Details Description
