Avago Technologies US, Inc. AEDC-5570-Z13
- Mfg. Part Number
- AEDC-5570-Z13
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- Encoders
- Brief Description
- ENCODER 3CH 5000CPR 8MM
- Datasheet Download
- AEDC-5570-Z13.pdf
Availability of AEDC-5570-Z13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 54.57000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AEDC-5570-Z13, we specialize in Avago Technologies US, Inc. all series electronic components. AEDC-5570-Z13 can be shipped within 24 hours after order. If you have any demands for AEDC-5570-Z13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AEDC-5570-Z13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AEDC-5570-Z13
| Internal Part Number | EIS-AEDC-5570-Z13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 30 | |
| Category | Sensors, Transducers | |
| Family | Encoders | |
| Series | - | |
| Encoder Type | Optical | |
| Output Type | Quadrature with Index (Incremental) | |
| Pulses per Revolution | 5000 | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Actuator Type | Hole for Shaft | |
| Detent | No | |
| Built in Switch | No | |
| Mounting Type | * | |
| Orientation | * | |
| Termination Style | * | |
| Rotational Life (Cycles Min) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AEDC-5570-Z13 | |
| Related Links | AEDC-5, AEDC-5570-Z13 Datasheet, Avago Technologies US, Inc. Distributor | |
AEDC-5570-Z13 Details Description
