Abracon Corporation AIUR-07-101K
- Mfg. Part Number
- AIUR-07-101K
- Manufacturer
- Abracon Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 100UH 390MA 660 MOHM
- Datasheet Download
- AIUR-07-101K.pdf
Availability of AIUR-07-101K
Available Quantity
5331 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.32000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AIUR-07-101K, we specialize in Abracon Corporation all series electronic components. AIUR-07-101K can be shipped within 24 hours after order. If you have any demands for AIUR-07-101K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AIUR-07-101K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AIUR-07-101K
| Internal Part Number | EIS-AIUR-07-101K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | AIUR-07.pdfAIUR-07.stp | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | AIUR-07 | |
| Packaging | Bulk | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 100µH | |
| Tolerance | ±10% | |
| Current Rating | 390mA | |
| Current - Saturation | 500mA | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 660 mOhm Max | |
| Q @ Freq | 43 @ 1kHz | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 85°C | |
| Frequency - Test | 1kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.236" Dia (6.00mm) | |
| Height - Seated (Max) | 0.201" (5.10mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AIUR-07-101K | |
| Related Links | AIUR-0, AIUR-07-101K Datasheet, Abracon Corporation Distributor | |
AIUR-07-101K Details Description
