Diodes Incorporated AL8807BMP-13
- Mfg. Part Number
- AL8807BMP-13
- Manufacturer
- Diodes Incorporated
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED DRIVER RGLTR DIM
- Datasheet Download
- AL8807BMP-13.pdf
Availability of AL8807BMP-13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.39200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AL8807BMP-13, we specialize in Diodes Incorporated all series electronic components. AL8807BMP-13 can be shipped within 24 hours after order. If you have any demands for AL8807BMP-13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AL8807BMP-13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AL8807BMP-13
| Internal Part Number | EIS-AL8807BMP-13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | DC DC Regulator | |
| Topology | Step-Down (Buck) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 1 | |
| Voltage - Supply (Min) | 6V | |
| Voltage - Supply (Max) | 36V | |
| Voltage - Output | 40V | |
| Current - Output / Channel | 1.3A (Switch) | |
| Frequency | 1MHz | |
| Dimming | PWM | |
| Applications | - | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | |
| Supplier Device Package | 8-MSOP-EP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AL8807BMP-13 | |
| Related Links | AL8807, AL8807BMP-13 Datasheet, Diodes Incorporated Distributor | |
AL8807BMP-13 Details Description
