Diodes Incorporated AM4953GSTR-G1
- Mfg. Part Number
- AM4953GSTR-G1
- Manufacturer
- Diodes Incorporated
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR DRIVER PAR 10SSOP
- Datasheet Download
- AM4953GSTR-G1.pdf
Availability of AM4953GSTR-G1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.33408
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AM4953GSTR-G1, we specialize in Diodes Incorporated all series electronic components. AM4953GSTR-G1 can be shipped within 24 hours after order. If you have any demands for AM4953GSTR-G1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AM4953GSTR-G1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AM4953GSTR-G1
| Internal Part Number | EIS-AM4953GSTR-G1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 4,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | - | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Driver - Fully Integrated, Control and Power Stage | |
| Output Configuration | Half Bridge (2) | |
| Interface | Parallel | |
| Technology | Bipolar | |
| Step Resolution | - | |
| Applications | Fan Motor Driver | |
| Current - Output | 800mA | |
| Voltage - Supply | 2.2 V ~ 16 V | |
| Voltage - Load | 2.2 V ~ 16 V | |
| Operating Temperature | -40°C ~ 105°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-SOP (0.154", 3.90mm Width) | |
| Supplier Device Package | 10-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AM4953GSTR-G1 | |
| Related Links | AM4953, AM4953GSTR-G1 Datasheet, Diodes Incorporated Distributor | |
AM4953GSTR-G1 Details Description
