Honeywell Sensing and Productivity Solutions AML24EBA2AA05-002
- Mfg. Part Number
- AML24EBA2AA05-002
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER SPDT 3A 125V
- Datasheet Download
- AML24EBA2AA05-002.pdf
Availability of AML24EBA2AA05-002
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 41.02000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AML24EBA2AA05-002, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. AML24EBA2AA05-002 can be shipped within 24 hours after order. If you have any demands for AML24EBA2AA05-002, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AML24EBA2AA05-002 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AML24EBA2AA05-002
| Internal Part Number | EIS-AML24EBA2AA05-002 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | AML Series LED Appl Note | |
| Design Resources | AML/MML Series Tech Guide | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | AML24 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | Mom-Off-Mom | |
| Current Rating | 3A (AC), 2A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 24V | |
| Actuator Type | Actuator Arm, Cap Required | |
| Color - Actuator/Cap | - | |
| Actuator Marking | Varies by Cap | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Rectangular - 28.98mm x 19.05mm | |
| Operating Temperature | - | |
| Mechanical Life | 25,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AML24EBA2AA05-002 | |
| Related Links | AML24EBA, AML24EBA2AA05-002 Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
AML24EBA2AA05-002 Details Description
