Sullins Connector Solutions AMM43DSEF-S243
- Mfg. Part Number
- AMM43DSEF-S243
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 86POS .156 EYELET
- Datasheet Download
- AMM43DSEF-S243.pdf
Availability of AMM43DSEF-S243
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 25.13700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AMM43DSEF-S243, we specialize in Sullins Connector Solutions all series electronic components. AMM43DSEF-S243 can be shipped within 24 hours after order. If you have any demands for AMM43DSEF-S243, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AMM43DSEF-S243 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AMM43DSEF-S243
| Internal Part Number | EIS-AMM43DSEF-S243 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tray | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 43 | |
| Number of Positions | 86 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.156" (3.96mm) | |
| Features | - | |
| Mounting Type | Panel Mount | |
| Termination | Solder Eyelet(s) | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Contact Type | Full Bellows | |
| Color | Green | |
| Flange Feature | Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia | |
| Operating Temperature | -65°C ~ 150°C | |
| Material - Insulation | Polyphenylene Sulfide (PPS) | |
| Read Out | Single | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AMM43DSEF-S243 | |
| Related Links | AMM43DS, AMM43DSEF-S243 Datasheet, Sullins Connector Solutions Distributor | |
AMM43DSEF-S243 Details Description
