Vishay Thin Film AORN2002AT5
- Mfg. Part Number
- AORN2002AT5
- Manufacturer
- Vishay Thin Film
- Product Category
- Resistor Networks, Arrays
- Brief Description
- RES NETWORK 4 RES 20K OHM 8SOIC
- Datasheet Download
- AORN2002AT5.pdf
Availability of AORN2002AT5
Available Quantity
5520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.68000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AORN2002AT5, we specialize in Vishay Thin Film all series electronic components. AORN2002AT5 can be shipped within 24 hours after order. If you have any demands for AORN2002AT5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AORN2002AT5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AORN2002AT5
| Internal Part Number | EIS-AORN2002AT5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Resistors | |
| Family | Resistor Networks, Arrays | |
| Series | AORN | |
| Packaging | Tape & Reel (TR) | |
| Circuit Type | Voltage Divider | |
| Resistance (Ohms) | 20k | |
| Tolerance | ±0.1% | |
| Number of Resistors | 4 | |
| Number of Pins | 8 | |
| Power Per Element | 100mW | |
| Temperature Coefficient | ±25ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Applications | Automotive AEC-Q200, Voltage Divider (TCR Matched) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Size / Dimension | 0.194" L x 0.157" W (4.93mm x 3.99mm) | |
| Height | 0.068" (1.73mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AORN2002AT5 | |
| Related Links | AORN2, AORN2002AT5 Datasheet, Vishay Thin Film Distributor | |
AORN2002AT5 Details Description
