Diodes Incorporated AP2132MP-1.2TRG1
-Exposed-Pad.jpg)
- Mfg. Part Number
- AP2132MP-1.2TRG1
- Manufacturer
- Diodes Incorporated
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 1.2V 2A
- Datasheet Download
- AP2132MP-1.2TRG1.pdf
Availability of AP2132MP-1.2TRG1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.20088
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AP2132MP-1.2TRG1, we specialize in Diodes Incorporated all series electronic components. AP2132MP-1.2TRG1 can be shipped within 24 hours after order. If you have any demands for AP2132MP-1.2TRG1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AP2132MP-1.2TRG1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AP2132MP-1.2TRG1
| Internal Part Number | EIS-AP2132MP-1.2TRG1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Cert of Compliance | |
| Standard Package | 4,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 1.2V | |
| Current - Output | 2A | |
| Voltage - Dropout (Typical) | 0.3V @ 2A | |
| Number of Regulators | 1 | |
| Voltage - Input | 1.4 V ~ 5.5 V | |
| Current - Limit (Min) | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | |
| Supplier Device Package | 8-PSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AP2132MP-1.2TRG1 | |
| Related Links | AP2132MP, AP2132MP-1.2TRG1 Datasheet, Diodes Incorporated Distributor | |
