Diodes Incorporated APT13005DTF-G1
- Mfg. Part Number
- APT13005DTF-G1
- Manufacturer
- Diodes Incorporated
- Product Category
- Transistors (BJT) - Single
- Brief Description
- TRANS NPN 450V 4A
- Datasheet Download
- APT13005DTF-G1.pdf
Availability of APT13005DTF-G1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.33600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of APT13005DTF-G1, we specialize in Diodes Incorporated all series electronic components. APT13005DTF-G1 can be shipped within 24 hours after order. If you have any demands for APT13005DTF-G1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- APT13005DTF-G1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
APT13005DTF-G1
| Internal Part Number | EIS-APT13005DTF-G1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Single | |
| Series | - | |
| Packaging | Box | |
| Transistor Type | NPN | |
| Current - Collector (Ic) (Max) | 4A | |
| Voltage - Collector Emitter Breakdown (Max) | 450V | |
| Vce Saturation (Max) @ Ib, Ic | 900mV @ 1A, 4A | |
| Current - Collector Cutoff (Max) | - | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 8 @ 2A, 5V | |
| Power - Max | 28W | |
| Frequency - Transition | 4MHz | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 Full Pack | |
| Supplier Device Package | TO-220F-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | APT13005DTF-G1 | |
| Related Links | APT1300, APT13005DTF-G1 Datasheet, Diodes Incorporated Distributor | |
APT13005DTF-G1 Details Description
