Abracon Corporation ASGTX-C-49.152MHZ-1
- Mfg. Part Number
- ASGTX-C-49.152MHZ-1
- Manufacturer
- Abracon Corporation
- Product Category
- Oscillators
- Brief Description
- OSC VCTCXO 49.152MHZ LVCMOS SMD
- Datasheet Download
- ASGTX-C-49.152MHZ-1.pdf
Availability of ASGTX-C-49.152MHZ-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 56.55000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ASGTX-C-49.152MHZ-1, we specialize in Abracon Corporation all series electronic components. ASGTX-C-49.152MHZ-1 can be shipped within 24 hours after order. If you have any demands for ASGTX-C-49.152MHZ-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ASGTX-C-49.152MHZ-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ASGTX-C-49.152MHZ-1
| Internal Part Number | EIS-ASGTX-C-49.152MHZ-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | ASGTX.pdfASGTX.stp | |
| Standard Package | 10 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | ASGTX | |
| Packaging | Bulk | |
| Type | VCTCXO | |
| Frequency | 49.152MHz | |
| Function | - | |
| Output | LVCMOS | |
| Voltage - Supply | 3.135 V ~ 3.465 V | |
| Frequency Stability | ±1ppm | |
| Operating Temperature | -30°C ~ 70°C | |
| Current - Supply (Max) | 45mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.354" L x 0.276" W (9.00mm x 7.00mm) | |
| Height | 0.088" (2.24mm) | |
| Package / Case | 6-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ASGTX-C-49.152MHZ-1 | |
| Related Links | ASGTX-C-4, ASGTX-C-49.152MHZ-1 Datasheet, Abracon Corporation Distributor | |
ASGTX-C-49.152MHZ-1 Details Description
