Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
| Internal Part Number | EIS-ATF1502AS-7AC44 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 154 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) | |
| Series | ATF15xx | |
| Packaging | Tray | |
| Programmable Type | In System Programmable (min 10K program/erase cycles) | |
| Delay Time tpd(1) Max | 7.5ns | |
| Voltage Supply - Internal | 4.75 V ~ 5.25 V | |
| Number of Logic Elements/Blocks | - | |
| Number of Macrocells | 32 | |
| Number of Gates | - | |
| Number of I/O | 32 | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 44-TQFP | |
| Supplier Device Package | 44-TQFP (10x10) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ATF1502AS-7AC44 | |
| Related Links | ATF1502, ATF1502AS-7AC44 Datasheet, Atmel Distributor | |
