Advanced Thermal Solutions Inc. ATS-12G-141-C1-R0
- Mfg. Part Number
- ATS-12G-141-C1-R0
- Manufacturer
- Advanced Thermal Solutions Inc.
- Product Category
- Thermal - Heat Sinks
- Brief Description
- HEATSINK 30X30X10MM L-TAB
- Datasheet Download
- ATS-12G-141-C1-R0.pdf
Availability of ATS-12G-141-C1-R0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.97000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ATS-12G-141-C1-R0, we specialize in Advanced Thermal Solutions Inc. all series electronic components. ATS-12G-141-C1-R0 can be shipped within 24 hours after order. If you have any demands for ATS-12G-141-C1-R0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ATS-12G-141-C1-R0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ATS-12G-141-C1-R0
| Internal Part Number | EIS-ATS-12G-141-C1-R0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | How to Install Push Pin Heat Sinks | |
| Design Resources | pushPIN™ Selector Tool | |
| Featured Product | ATS - pushPIN™ Heat-sinks | |
| Standard Package | 1 | |
| Category | Fans, Thermal Management | |
| Family | Thermal - Heat Sinks | |
| Series | pushPIN™ | |
| Type | Top Mount | |
| Package Cooled | Assorted (BGA, LGA, CPU, ASIC...) | |
| Attachment Method | Push Pin | |
| Shape | Square, Fins | |
| Length | 1.181" (30.00mm) | |
| Width | 1.181" (30.00mm) | |
| Diameter | - | |
| Height Off Base (Height of Fin) | 0.394" (10.00mm) | |
| Power Dissipation @ Temperature Rise | - | |
| Thermal Resistance @ Forced Air Flow | 15.66°C/W @ 100 LFM | |
| Thermal Resistance @ Natural | - | |
| Material | Aluminum | |
| Material Finish | Blue Anodized | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ATS-12G-141-C1-R0 | |
| Related Links | ATS-12G-, ATS-12G-141-C1-R0 Datasheet, Advanced Thermal Solutions Inc. Distributor | |
ATS-12G-141-C1-R0 Details Description
