Atmel ATSAMD21J15B-AF
- Mfg. Part Number
- ATSAMD21J15B-AF
- Manufacturer
- Atmel
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT 32KB FLASH 64TQFP
- Datasheet Download
- ATSAMD21J15B-AF.pdf
Availability of ATSAMD21J15B-AF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.89504
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ATSAMD21J15B-AF, we specialize in Atmel all series electronic components. ATSAMD21J15B-AF can be shipped within 24 hours after order. If you have any demands for ATSAMD21J15B-AF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ATSAMD21J15B-AF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ATSAMD21J15B-AF
| Internal Part Number | EIS-ATSAMD21J15B-AF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | SAM D21J | |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-M0+ | |
| Core Size | 32-Bit | |
| Speed | 48MHz | |
| Connectivity | I²C, LIN, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | |
| Number of I/O | 52 | |
| Program Memory Size | 32KB (32K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 4K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.62 V ~ 3.6 V | |
| Data Converters | A/D 20x12b, D/A 1x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 64-TQFP | |
| Supplier Device Package | 64-TQFP (10x10) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ATSAMD21J15B-AF | |
| Related Links | ATSAMD2, ATSAMD21J15B-AF Datasheet, Atmel Distributor | |
